DANOSA ACOUSTIC MEMBRANE M.A.D.2
Danosa Acoustic Membrane M.A.D.2 is a high density bitumen modified membrane specifically designed to behave as an anti resonant material。
It is an efficient substitute for lead sheets. Between porous absorbers materials works like a panel absorbers (most efficient at absorbing low frequencies)。
PRESENTATION
|
PRESENTATION |
VALUE |
UNIT |
|
Length |
12 |
m |
|
Width |
1 |
m |
|
Total thickness |
2 |
mm |
ECHNICAL DATA
|
TECHNICAL DATA |
VALUE |
UNIT |
STANDARD |
|
Thickness tolerance |
< 10 |
% |
EN 823 |
|
Length and width tolerance |
< 5 |
% |
EN 822 |
|
Nominal mass |
> 3 |
kg/㎡ |
EN 1849-1 |
|
Tensile strength: longitudinal |
260 |
N/5cm |
EN 12311-1 |
|
Tensile strength: tranversal |
175 |
N/5cm |
EN 12311-1 |
|
Resistance to tearing (nail shank) |
125±50 |
KN/m |
EN 12310-1 |
|
Dimensional stability at elevated temperature |
stable |
- |
EN 1107-1 |
|
Reaction to fire |
C s3 d0 |
- |
EN 13501-1 |
|
Sound reduction index improvement between plasterboard |
4 |
dB |
EN 140-16 |
|
Insulation improvement to 125 Hz (rigid elements) |
>4 |
dB |
EN 140-16 |
|
Insulation improvement to 125 Hz (like panel absorber) |
>8 |
dB |
EN 140-16 |
STANDARDS AND CERTIFICATION
Acoustic certifications resulting from approved laboratory tests。
|
Laboratory |
Test (EN 140-3) No |
Result (EN 717-1) |
|
L.G.A.I. |
97.017.995 |
Rw= 33 dB |
|
DANOSA |
95/MAD/004 |
Rw= 37 dB |
Test Report
SCOPE
Used between rigid elements such as plasterboards to improve the low frequency insulation。
Used between spring elements (fibers, rock wool) to increase the overall insulation treatment, improving significantly against low frequencies through the membrane effect within mass-spring-mass system。
It used as antiresonant material in industrial acoustic insulation, providing acoustic mass to the galvanized steel sheet。
INSTRUCTION FOR USE
An installation of the Danosa Acoustic Membrane is shown in the following pictures：
1、Staple on 1st plate (wall)
2、Place the second plate (wall)
3、Staple on 1st plate (floating ceiling)
4、Set the 2nd plate (floating ceiling)
